Image Resolution

1MP: 1280×960; 3MP: 2048×1536; 5MP: 2529×1944; 8MP: 3264×2488; 12MP: 4000×3000; 16MP: 4608×3450

Video Resolution

WVGA: 640×480@30fps; VGA: 720×480@30fps; 720P: 1280×720@60fps, high-speed photography 1280×720@30fps; 1080P: 1920×1080@30fps; 4K: 2688×1520@20fps

Time-lapse Video Resolution

2592×1944; 2048×1536

Operation Mode

Day/Night, Switch automatically

Lens

FOV=50°, F=2.5, Auto IR-Cut

IR Flash

82 Feet/25 Meters

IR Setting

42 LEDs: 850nm or 940nm

LCD Screen

2.4" TFT Color Display

Operation Keypad

7 buttons

Beep Sounds

On/Off

Memory

SD Card(≤256GB)

PIR Level

High/Normal/Low

PIR Sensing Distance

82 Feet/25 Meters

PIR Sensor Angle

50°

Trigger Time

0.2 Seconds(as fast as 0.15s)

PIR Sleep

5 Seconds~60 Minutes, Programmable

Loop Recording

On/Off, when the SD card is full, the earliest file will be automatically overwritten

Shooting Numbers

1/2/3/6 Photos

Write Protection

Lock partial or all photos to avoid being deleted; Unlock

Video Length

5 Seconds~10 Minutes, Programmable

Camera + Video

First take Picture then Video

Playback Zoom

1~8 Times

Slide Show

Yes

Stamp

Options: Time & Date/Date/Off/No LOGO; Display content: Logo, Temperature, Moon Phase, Time and Date, Photo ID

Timer

On/Off, 2 time periods can be set

Interval

3 Seconds~24 Hours

Password

4 Digit or Alphabets

Device No.

4 Digit or Alphabets

Longitude&Latitude

N/S: 00°00'00"E; E/W: 00°00'00"

Simple Menu

On/Off

Power Supply

4×AA, Expandable to 8×AA

External DC Power Supply

6V/2A

Stand-by Current

200μA

Stand-by Time

One Year(8×AA)

Power Consumption

260mA (+790mA when IR LED lights up)

Low Battery Alarm

4.15V

Interface

TV-out/USB, SD card slot, 6V DC External

Mounting

Strap; Tripod Nail

Waterproof

IP66

Work Temperature

-22～+158°F/-30～+70°C

Work Humidity

5%～95%

Certification

FCC&CE&ROHS

Dimensions

148×99×78(mm)

Weight

320g
