Work Mode

Camera

Video

Camera+Video

Time-lapse Video

Image Size

1MP：1280×960

3MP：2048×1536

5MP：2592×1944

8MP：3264×2488

12MP：4000×3000

Video Size

WVGA: 640x480

VGA: 720x480

720P: 1280x720@30fps

1080P: 1920x1080@17fps

Operation Mode

Day/Night, Switch automatically

Lens

FOV＝50°, F=2.5, Auto IR-Cut

IR Flash

82 Feet/25 Meters

IR Setting

48 LEDs; 850nm or 940nm

LCD Screen

2.4" TFT Color Display

Operation Keypad

7 buttons

Beep Sounds

On/Off

Memory

SD Card(≦32GB)

PIR Level

High/Normal/Low

PIR Sensing Distance

82 Feet/25 Meters

PIR Sensor Angle

50°

Trigger Time

0.6 Seconds(When using 2GB SD card)

PIR Sleep

5 Seconds～60 Minutes, Programmable

Shooting Numbers

1/2/3/6 Photos

Protection

Lock partial or all photos to avoid being deleted; Unlock

Video Length

5 Seconds～10 Minutes, Programmable

Camera + Video

First take Picture then Video

Loop Recording

On/Off

Playback Zoom

1～8 Times

Slide Show

Yes

Stamp

On/Off, Temperature, Moon Phase, Logo, Time and Date, Photo ID

Timer

On/Off, Programmable

Interval

3 Seconds～24 Hours

Password

4 Digit Numbers

Device No.

4 Digit and 26 Alphabet set by yourself

Power Supply

4×AA, Expandable to 8×AA

External DC Power Supply

6V/2A

Stand-by Current

330μA

Stand-by Time

4～8 Months(4×AA～8×AA)

Power Consumption

160mA (+1140mA when IR LED lights up)

Low Battery Alarm

4.6V

Interface

TV-out, USB,SD card slot,6V DC External

Mounting

Strap; Tripod Nail

Waterproof

IP66

Work Temperature

-22～＋158°F/-30～＋70°C

Work Humidity

5%～95%
