Model: 4.0T-CG
Features
Specification
Beyond standard features, this camera delivers reliable performance with standout capabilities including real GPS, automatic SIM configuration, daily reports, and remote app control (iOS & Android). It offers 20m true night vision, a 0.4-second trigger, and multi-shot capture (up to 5 photos per trigger) for complete motion tracking. The intuitive menu ensures user-friendly operation.
◆ Regular lens model: 60° FOV lens; 60° PIR angle
◆ Wide lens model: 100° FOV Lens; 100° PIR angle
◆ Programmable 5/8/12/24 Megapixel high-quality resolution
◆ APP available in IOS & Android APP store
◆ Available operation temperature: -25℃ to 60℃
Image Sensor | Pixel | 5 megapixels |
Scale | 4:3 | |
Lens | DFOV | Regular angle version: 60°; Wide angle version: 100° |
F No. | Regular angle version: F2.0;Wide angle version: F2.4 | |
Wireless Module | LTE UE Category | CAT1 bis |
Band | For Europe: B1/B3/B5/B7/B8/B20/B28;For America: B2/B4/B5/B12/B13/B66 | |
Protocol | Support SMTP, SMTPS, FTP, FTPS | |
PIR | Trigger Angle | Regular angle version: 60°;Wide angle version: 100° |
Trigger Distance | 20m(max) | |
Screen | Size | 2.0 inch |
Type | TFT | |
Resolution | 320 x 240 | |
IR LED | Wavelength | 940nm |
Quantity | 59 pieces | |
SD Card | Capacity | Routine: 8GB to 32GB;Maximum: 128GB (Require formatting for over 32 GB) |
Interface | Slot | SD card slot;SIM card slot |
Port | USB-C port;DC port | |
Photo Parameters | Taking Photo Size | 5M: 2560x1920;8M: 3264x2448;12M: 4032x3024;24M: 5632x4224;32M: 6528x4896 |
Sending Photo Size | Small: 1280x960;Bigger: 1984x1488;HD: same as Taking Photo Size | |
Photo Format | .jpg | |
Video Parameters | Taking Video Size | WVGA: 848x480;HD: 1280x720;FHD: 1920x1080 |
Taking Video Length | 5/10/15/20/30/40/50/59s | |
Sending Video Size | WVGA-848x480;HD-1280x720;FHD-1920x1080 | |
Sending Video Length | WVGA: 5/10/15s;HD: 5/10/15s;FHD: 5s | |
Video Format | .mp4 | |
Encoding | H.265 | |
Performance Parameters | Rated Input Voltage | 9~12V |
Trigger Time | 0.3s | |
Operating Temperature | -20°C to 55°C | |
Storage Temperature | -25°C to 60°C | |
Operation Humidity | 5%-90% | |
Waterproof Spec | IP66 | |
Dimensions | Including 4G antenna: 367mm x 116mm x 72mm;Excluding 4G antenna: 152mm x 116mm x 72mm | |
Weight | Including 4G antenna: 403g;Excluding 4G antenna: 363g | |
Certification | CE, FCC, RoHS | |
