Effective Pixels

2304×1296

Day/Night Mode

Yes

IR Range

20m

IR Setting

60pcs; 940nm-IR LED

Memory

SD Card (4GB - 32GB)

Operating Keys

4

Lens

F=2.0; FOV=60°; Auto IR-Cut-Remove (at night)

PIR Angle

60°

PIR Distance

20m

LCD Screen

No

Picture Size

3MP/5MP = 2304×1296/3072×1728; Transmitting Thumbnail to APP (640×360)

Shooting Numbers

1P/2P/3P

Picture Format

.jpg

Video Resolution

WVGA/720P/1080P = 864×486/1280×720/1920×1080

Video Length

10sec.

Video Format

.mp4

Trigger Time

0.5-0.6s

Trigger Interval

30s-35s

Camera + Video

Yes

Time Lapse

Yes

GPS

No

SD Card Cycle

ON/OFF

Operation Power

Battery: 12V; DC: 12V-2A

Battery Type

12AA

External DC

12V

Stand-by Current

0.165mA

Stand-by Time

6-8 months

Auto Power Off

In Setup mode, camera will automatically power off in 3 mins if there is no keypad touching.

Wireless Module

LTE Cat1 module; 2G & 3G networks are also supported in some countries.

Interface

Type-C/DC Port/SIM Card/SD Card

APP

"Trailcam Ace" Support Android/iOS system

Mounting

Antenna; Strap; Instruction Book

Operating Temperature

-20°C to 55°C

Storage Temperature

-25°C to 60°C

Operation Humidity

5%-90%

Waterproof Spec

IP66

Dimensions

140.0×110.0×90.0 mm

Weight

425.0 g

Certification

CE FCC RoHS
